What do I need to know before....

Msfitoy

Well-Known Member
First Name
Sid
Joined
Mar 5, 2019
Threads
61
Messages
7,757
Reaction score
22,642
Location
North Carolina
Vehicle(s)
2019 Ranger, 2003 MINI Cooper S, 2021 Honda CT125
Occupation
Automotive, Industrial Designer
Vehicle Showcase
1
...I kill myself tomorrow? o_O

Tips appreciated.



If I had to do it again, I'd find a shop to mount the springs...those tools are pretty sketchy and are widow makers for a good reason...shops have special compression tools that can do it fast/safe and without marring up your tubes... ?

OP
OP
OFC Ranger

OFC Ranger

Well-Known Member
First Name
Jack
Joined
Aug 3, 2020
Threads
291
Messages
4,809
Reaction score
13,303
Location
Georgia
Vehicle(s)
ZR2
Vehicle Showcase
1
If I had to do it again, I'd find a shop to mount the springs...those tools are pretty sketchy and are widow makers for a good reason...shops have special compression tools that can do it fast/safe and without marring up your tubes... ?
Well I already planned to do the compression and all that aimed at a 6x6 fence post so I have that much covered haha.


Msfitoy

Well-Known Member
First Name
Sid
Joined
Mar 5, 2019
Threads
61
Messages
7,757
Reaction score
22,642
Location
North Carolina
Vehicle(s)
2019 Ranger, 2003 MINI Cooper S, 2021 Honda CT125
Occupation
Automotive, Industrial Designer
Vehicle Showcase
1
Curious why you didn't "borrow" the clamp tools from Autozone?



OP
OP
OFC Ranger

OFC Ranger

Well-Known Member
First Name
Jack
Joined
Aug 3, 2020
Threads
291
Messages
4,809
Reaction score
13,303
Location
Georgia
Vehicle(s)
ZR2
Vehicle Showcase
1
Curious why you didn't "borrow" the clamp tools from Autozone?
Not that expensive really and I figured at some point in the future I may need them again or need to help a family or friend.


Elmosaurus

Well-Known Member
Joined
Nov 27, 2021
Threads
11
Messages
202
Reaction score
659
Location
Harveys Lake, PA
Vehicle(s)
2022 Ford Ranger (SCrew Lariat Tremor)
Ahh the memories. Smashed my thumb one time using my set of spring compressors....

Smear a light coat of grease on the threads of the all thread rods. You do NOT want those binding up as you turn the rod. Do NOT get that grease on the spring seats. (bad juju if you do)

Do NOT turn one rod more than a turn or two, before switching over to the other side. Once one side gets too far compressed, the other side can get loose and swing around. (see comment about smashed thumb above) This makes it a REALLY slow and arduous process... but, deal with it; that's the penalty for using this tool.

I'll finish by saying that It's a tool that works, but it's the most ancient of ways to do it. If you have a spare vehicle, it's actually worth just removing the assembly from the truck, bringing it as a whole with the new shocks/struts to a shop and having them use their large machine to replace quickly. Most decent shops won't charge more than a few bucks for a pair, provided they don't have to remove or install onto a vehicle. (my local guy will do all four corners for me now for $20, but they've known me well for years now)


D Fresh

Banned
Banned
First Name
Doug
Joined
Dec 10, 2020
Threads
20
Messages
6,282
Reaction score
13,548
Location
Colorado
Vehicle(s)
'20 Lariat FX4, '17 FiST, '16 CX-5, '95 YJ
Occupation
Milkman
Not that expensive really and I figured at some point in the future I may need them again or need to help a family or friend.
Agreed, always buy the tool vs rent if the cost difference is neglible.

Tools are good!
