Here's a few pics of the receiver. It wasn't possible to get pics of how it bolts to the frame rail without removing the front skid plate, so the pdf shows how it was built.
Sorry, but I can't remember the sizes the metal used, but if you look at the pdf, I used a piece of C-channel that fit around the frame rail and on the upper and lower ends of the channel and welded flat bar (vertically) to accept a couple bolts. Then I cut a piece of plate steel for the opposite side of the frame rail so I could bolt the 2 pieces together and "sandwich" the frame rail.
2" tubing was cut and welded, so the receiver would end up where it did.
I also added a front support tab. I think it bolts to an existing oem hole, but can't fully remember. I may have had to drill a hole?
I plan to do an oil change soon, so when I do that, I'll see if I can get better pics.
Sorry, but I can't remember the sizes the metal used, but if you look at the pdf, I used a piece of C-channel that fit around the frame rail and on the upper and lower ends of the channel and welded flat bar (vertically) to accept a couple bolts. Then I cut a piece of plate steel for the opposite side of the frame rail so I could bolt the 2 pieces together and "sandwich" the frame rail.
2" tubing was cut and welded, so the receiver would end up where it did.
I also added a front support tab. I think it bolts to an existing oem hole, but can't fully remember. I may have had to drill a hole?
I plan to do an oil change soon, so when I do that, I'll see if I can get better pics.
