Wheel Spacers... safe?

ElSolo

Well-Known Member
First Name
Rick
Joined
Jul 14, 2020
Messages
51
Reaction score
112
Location
Santa Barbara, CA
Vehicle(s)
2020 Ford XLT, Lightning Blue, FX2 pkg, 301A pkg, Tow pkg.
Hello All,

I'm going to be the first to admit that I don't know a whole ton about mechanics and specs. I'm looking for a bigger tire for the stock 17" wheels that came with my Ranger XLT with the Sport appearance. Will I need wheel spacers? If so, are wheel spacers safe to use?

Thanks ahead of time.





Advertisement



Shadowdraxx

Well-Known Member
First Name
Ric
Joined
Sep 3, 2020
Messages
73
Reaction score
143
Location
TX
Vehicle(s)
2020 Ranger XLT Sport
Occupation
Bum
Spacers are fine as long as you get well made hubcentric ones spec to ford trq ratings and check them often to ensure they are tight.

will you need them? No if you are planing to just go to 265/70/17 on OEM but if you want to go bigger id personally get better offset lighter wheels, you don’t want too much weight on the hubs etc but that’s just my personal take.

also worth noting u would most likely have to do some cutting or removal of the crash bars and a lift on anything over the above sizing.


Msfitoy

Well-Known Member
First Name
Sid
Joined
Mar 5, 2019
Messages
2,709
Reaction score
4,948
Location
North Carolina
Website
www.coroflot.com
Vehicle(s)
2003 MINI Cooper S Modified, 2009 Chevy Cobalt SS Turbo Modified (sold)
Occupation
Mack Trucks Senior Industrial Designer
Vehicle Showcase
2
Hello All,

I'm going to be the first to admit that I don't know a whole ton about mechanics and specs. I'm looking for a bigger tire for the stock 17" wheels that came with my Ranger XLT with the Sport appearance. Will I need wheel spacers? If so, are wheel spacers safe to use?

Thanks ahead of time.
3 thousand miles on my 1.25" spacer and all is well...the spacers needs to be red loctite to the hub (100ft/lbs)...mine are actually for TACO which have the same thread/lug pattern so they are NOT hubcentric...because of 6 lugs, it is lugcentric...and it's all AOK...I didn't know at the time but when I installed my Fuel wheels 50,000 miles ago, they were not hubcentric either...proving that if lugs are torqued properly in star pattern, it will center just fine...

I believe spacers are safe with caveat...I drive like a grandma with occasional lead foot 😜


GTGallop

Well-Known Member
First Name
Greg
Joined
Mar 1, 2020
Messages
384
Reaction score
656
Location
Cave Creek, AZ
Website
www.qrz.com
Vehicle(s)
2019 Ranger XLT 4X4
Occupation
Project Manager
Spacers are fine as long as you get well made hubcentric ones spec to ford trq ratings and check them often to ensure they are tight.

will you need them? No if you are planing to just go to 265/70/17 on OEM but if you want to go bigger id personally get better offset lighter wheels, you don’t want too much weight on the hubs etc but that’s just my personal take.

also worth noting u would most likely have to do some cutting or removal of the crash bars and a lift on anything over the above sizing.
I'm thinking about some quarter inch spacers now. By my calculations that will make a slight difference when I go 265/70/17.

But the Quarter Inchers are bolt THROUGH not bolt ON. Same concerns still apply? Will I need longer lugs?


Msfitoy

Well-Known Member
First Name
Sid
Joined
Mar 5, 2019
Messages
2,709
Reaction score
4,948
Location
North Carolina
Website
www.coroflot.com
Vehicle(s)
2003 MINI Cooper S Modified, 2009 Chevy Cobalt SS Turbo Modified (sold)
Occupation
Mack Trucks Senior Industrial Designer
Vehicle Showcase
2
I'm thinking about some quarter inch spacers now. By my calculations that will make a slight difference when I go 265/70/17.

But the Quarter Inchers are bolt THROUGH not bolt ON. Same concerns still apply? Will I need longer lugs?
1/4"...no you don't need longer studs


OFC Ranger

Well-Known Member
First Name
Jack
Joined
Aug 3, 2020
Messages
789
Reaction score
1,267
Location
Georgia
Vehicle(s)
2019 RWD XLT
Occupation
We Wo We Wo We Wo
Vehicle Showcase
1
1. American Made

2. Hubcentric

3. T6 (or better) Aluminum CNC machined out of a single block

4. Grade 8 (or better) pressed studs

5. Red Locktite (and re-check after first 50 miles or so)

Quality spacers cost money. If you can get a set of four on eBay for $60 then steer clear. I would say $150'ish (for 1.25 to 2.00) is the minimum price point to get the above requirements. You don't have to get BORA to get quality, however if you have the cash by all means.


Msfitoy

Well-Known Member
First Name
Sid
Joined
Mar 5, 2019
Messages
2,709
Reaction score
4,948
Location
North Carolina
Website
www.coroflot.com
Vehicle(s)
2003 MINI Cooper S Modified, 2009 Chevy Cobalt SS Turbo Modified (sold)
Occupation
Mack Trucks Senior Industrial Designer
Vehicle Showcase
2

Ronbo

Well-Known Member
Joined
Aug 10, 2019
Messages
200
Reaction score
1,032
Location
Floriduh
Vehicle(s)
19 Ford Ranger SCrew, FX4. Ordered: 7/29/19 Built: 9/9/19 Delivered: 9/25/19
Occupation
Cowboy Astronaut Millionaire
Vehicle Showcase
1
Here’s what can happen if you don’t do it right. I see these crashes almost every week on my job. This guy had 2” spacers and monster heavy tires. Wheel failed on highway but luckily he didn’t crash into anyone else.


OFC Ranger

Well-Known Member
First Name
Jack
Joined
Aug 3, 2020
Messages
789
Reaction score
1,267
Location
Georgia
Vehicle(s)
2019 RWD XLT
Occupation
We Wo We Wo We Wo
Vehicle Showcase
1
Here’s what can happen if you don’t do it right. I see these crashes almost every week on my job. This guy had 2” spacers and monster heavy tires. Wheel failed on highway but luckily he didn’t crash into anyone else.
Trooper or wrecker? I'll hold back my memes since I don't know. haha


DT444T

Well-Known Member
First Name
Jake
Joined
Aug 10, 2020
Messages
154
Reaction score
293
Location
Michigan
Vehicle(s)
2019 Ranger Sport 4x4 Lariat - Saber, 1991 300ZX Turbo 5sp, 2015 BMW S1000RR, Yamaha R3 Track bike
Occupation
I'm fly. I'm pilot.
3 thousand miles on my 1.25" spacer and all is well...the spacers needs to be red loctite to the hub (100ft/lbs)...mine are actually for TACO which have the same thread/lug pattern so they are NOT hubcentric...because of 6 lugs, it is lugcentric...and it's all AOK...I didn't know at the time but when I installed my Fuel wheels 50,000 miles ago, they were not hubcentric either...proving that if lugs are torqued properly in star pattern, it will center just fine...

I believe spacers are safe with caveat...I drive like a grandma with occasional lead foot 😜
Are these spacers with stock wheels? If yes, hows the fit? I'm looking to space my stock wheesl out to a more flush look and I don't know what size to get.


Msfitoy

Well-Known Member
First Name
Sid
Joined
Mar 5, 2019
Messages
2,709
Reaction score
4,948
Location
North Carolina
Website
www.coroflot.com
Vehicle(s)
2003 MINI Cooper S Modified, 2009 Chevy Cobalt SS Turbo Modified (sold)
Occupation
Mack Trucks Senior Industrial Designer
Vehicle Showcase
2
Are these spacers with stock wheels? If yes, hows the fit? I'm looking to space my stock wheesl out to a more flush look and I don't know what size to get.
No they're not...they're mounted with +20 offset wheels and I have 2" fender flares...in light of this, I don't know how to advise your fitment =(


DT444T

Well-Known Member
First Name
Jake
Joined
Aug 10, 2020
Messages
154
Reaction score
293
Location
Michigan
Vehicle(s)
2019 Ranger Sport 4x4 Lariat - Saber, 1991 300ZX Turbo 5sp, 2015 BMW S1000RR, Yamaha R3 Track bike
Occupation
I'm fly. I'm pilot.
No they're not...they're mounted with +20 offset wheels and I have 2" fender flares...in light of this, I don't know how to advise your fitment =(
No problem, thanks.


RANGER PRIDE

Well-Known Member
Joined
Sep 4, 2019
Messages
2,682
Reaction score
4,485
Location
Canada, somewhere. A nomadic traveller
Vehicle(s)
2019 Ranger FX4 Supercrew
hang a plumb bob from your fender, flush if thats what you're looking for and measure to the tire wall. that will tell you what thickness spacer you need
