RCMUSTANG's Magnetic FX4

Stevie Gee

Well-Known Member
First Name
Steve
Joined
Nov 5, 2018
Messages
374
Reaction score
1,012
Location
Rancho Santa Margarita (Orange County),CA
Vehicle(s)
2019 Ranger Lariat SuperCrew FX4
Occupation
Retired Fed - H.U.D. (Housing and Urban Development)
Vehicle Showcase
1
Auto folding mirrors. Folds closed when you lock the truck. Unfolds when you power up the truck. Regular operation with stock switch. 20 minute install.
The switch bezel pops right off.
Unplug the connector.
Plug the module in between the switch and connector.
Tuck everything inside.
I used an add a tap to #30 for the constant for the red wire.
Connect the blue wire to the thick gray with brown stripe (lock).
Stick the module on the inside of the left side of the dash and tied up all the wiring. Close up fuse panel and you're done.
Hi Ray…I’m just now, almost 2 years later installing the mirror module….one question: WHERE/ TO WHAT DO I CONNECT THE GREEN WIRE? Thanx🙏🏾

OP
OP
RCMUSTANG

RCMUSTANG

Well-Known Member
First Name
Ray
Joined
Jan 22, 2019
Messages
1,577
Reaction score
1,462
Location
Los Angeles
Vehicle(s)
2017 Fusion 1995 Ranger
Hi Ray…I’m just now, almost 2 years later installing the mirror module….one question: WHERE/ TO WHAT DO I CONNECT THE GREEN WIRE? Thanx🙏🏾
Does it do what you want it to do?


Stevie Gee

Well-Known Member
First Name
Steve
Joined
Nov 5, 2018
Messages
374
Reaction score
1,012
Location
Rancho Santa Margarita (Orange County),CA
Vehicle(s)
2019 Ranger Lariat SuperCrew FX4
Occupation
Retired Fed - H.U.D. (Housing and Urban Development)
Vehicle Showcase
1
Does it do what you want it to do?
Yes…got it, thanx. I read through more posts and did NOT connect the green wire to anything.
